The new generation of Wi-Fi technology, Wi-Fi 6, offers a paradigm shift at the network edge: not just faster speeds as in previous generation changes, but a shift to high-efficiency Wi-Fi for substantially improved capacity, better coverage and reduced network congestion, using key technologies such OFDMA and Uplink and Downlink MU-MIMO
Extreme Networks Wi-Fi 6
What is Wi-Fi 6?
Why is Wi-Fi 6 important?
Wi-Fi network usage continues to grow therefore capacity must grow too. Wi-Fi 6 ensures that high demand networks can cope with the onslaught of corporate, guest, BYOD, and IoT devices that flood every organization today.
Wi-Fi 6 is protects bandwidth through traffic optimization and prioritization, instead of simply throwing more capacity at the problem.Wi-Fi 6 takes a much more intelligent approach to the sustainability and longevity of your mobility infrastructure.
Learn more about
Extreme Wi-Fi 6 from Altura
Wi-Fi 6 improves your network performance with these technologies:
1024 – QAM Modulation
Modulation techniques are used to optimize throughput and range. The number of points in the modulation constellation determines the number of bits conveyed with each symbol. 802.11ac uses 256 QAM which transfers 8 bits/symbol. 802.11ax supports 1024 QAM, using 10 bits/symbol for a 25% increase in throughput.
Introduced in 11ac, MU-MIMO technology allows the simultaneous transmitting of multiple frames to different receivers at the same time on the same channel using multiple RF streams to provide greater efficiency. 11ax adds 8×8 and Uplink MU-MIMO services to provide significantly higher data throughput.
Multi-user version of OFDM enabling concurrent AP communication (Uplink/Downlink) with multiple clients by assigning subsets of subcarriers, called Resource Units (RUs) to the individual clients. Based on client traffic needs, the AP can allocate the whole channel to only one user or may partition it to serve multiple users simultaneously.
OBSS (BSS coloring)
To improve spatial reuse efficiency and performance, 11ax adjusts the carrier sense operation based on the ‘color’ of the BSS. Depending on the BSS the traffic is generated from, the station can use different sensitivity thresholds to transmit or defer. This results in higher overall performance.
Power Saving with TWT
TWT allows the AP to schedule a series of times for a station to ‘wake up’ at scheduled intervals to exchange data frames. This allows the station to ‘sleep’ longer and reduces energy consumption. It’s a key capability for IOT devices.
New Frame Formats
Modified frame formats provide High Efficiency (HE) and legacy information to support new advanced capabilities as well as information required to support legacy stations and backward compatibility.
